智能卡高精密铣刀,ABS铣刀,智能卡高精密铣刀,智能卡铣刀
更多在库品详情可参考LZQ官网的电子样册
刃型：（标准及非标准1-12刃系列铣刀、铰刀）：深沟型，圆头型，端角R型，空芯型，斜刃（锥度）型，长刃型，铝、铜专用，分屑槽（粗铣用）.
刃径：（微小型）φ0.10mm-φ53.00mm（整体钨钢）、φ20.00mm-φ80.00mm(焊刃式).
公差：（标准及非标准）钻石钨钢类刃径公差高要求的可至±0.001mm(±1μm)的精度范围，
柄径公差均为h6以上.
螺旋角：0°、25°、30°、35°、45°、50°、55°、60°.
材种:
●高耐冲击钻石钨钢（断续切削用）PRA11/VRA201系列。
●高硬度钻石钨钢（高耐磨用）HRF10/SR10T系列。
●ISO标准钨钢类（一般加工用）PR40/PRA5系列。
●高钴HSCo8（SKH59）、ASP60C德标
冷硬加工取代磨削可提高精度,硬铣削取代研磨可提高效率.
(高硬度钢加工用非涂层钻石钢刀具可替代TiALN涂层超微粒钨钢、陶瓷、CBN刀具切削后具有极佳的光洁度及较低的刀具成本).
微小径和成型复合刀具可依图纸或样品加工.
极超微粒、超长切割寿命、无与伦比的耐用度可来图、来样定做试试比比......
More information about our products in stock, please visit ouronline catalog on LZQ's officialwebsite.
Type of flute: (standardand non-standard 1-flute~12-flute series mill, reamer): deep groove, roundhead, end angle R, hollow, oblique flute (tapered), long flute, for aluminum,copper application, chip-dividing groove (for rough mill application)
Mill diameter: (miniature) φ0.10mm---φ53.00mm (solid tungsten steel),φ20.00mm--φ80.00mm (brazing)
Tolerance: (standard andnon-standard) tolerance of flute diameter of diamond tungsten steel can be upto ±0.001mm (±1μm) high, and tolerance of holder diameter is more than h6.
Helical angle:0°,25°,30°,35°,45°,50°,55°,60°
Grades:
●High-impact-resistant diamond tungsten steel (for intermittentcutting) PRA11/VRA201
●High hardness diamond tungsten steel (for high wearresistance) HRF10/SR10T
●Tungsten steel meeting ISO standard (for general machining)PR40/PRA5
●High cobalt HSCo8(SKH59), ASP60 German standard
Cold-hard machining replacing grinding can improve precision, hardmilling replacing grinding can improve efficiency.
(Non-coated diamond steel tooling for high hardness steel machiningcan replace TiALN coated ultra micro-grain carbide, ceramics.
Miniature and profile compound tooling canbe machined according to drawing or sample.
