专业特殊、非标、异型、新产品、任意种类、形状、公差的超硬加工。
※如有类似，可FAX地址，来电索取图片中的样品及相关样本资料供参考（只限小金额）※
常年備存原材料、半成品、成品 2000萬 ~3000萬RMB周转的在庫品，依圖依樣現生產，具有極強的性價比……欢迎实地指导。
（超高精密度/超高耐磨/高耐冲击用）
可以生产高精密成型模具，内孔可达到镜面效果。
★依图依样依要求可现生产超长超宽超厚、高精密度、形状极为复杂的成型制品。
VRA201 进口极超微粒钻石钨钢:
具有极为优秀的抗冲击性能和一般的耐磨耗性能。一般用于较差或普通的设备加工较低硬度的材料（HRC≤25°）、间断切削和很差的零件夹紧。相应ISO K25，可替代M42、ASP60、MPM、HSSCo10等材料的加工，并可取得4~6倍左右的使用寿命。具有极强的性价比。相应SKH51具有15～25倍的使用寿命及耐用度。
HRF10极超微粒钻石钨钢:
具有极为优秀的耐磨耗性能，但抗冲击性能略差。适用于调质或淬火等高硬度材料（HRC45°~65°）的中低速或要求具有较高的耐磨性能及有色金属等各类材料的中低速轻切削加工。一般用于良好的工况、稳定的切削、优良的零件装夹及持续的轻型加工。相应ISO K10。
MT11（高耐磨用）极超微粒钻石钨钢:
具有极为优秀的耐磨耗性能及理想的抗冲击性能。适用于HRC28°~48°各类材料的中、高速中等切削加工至精加工，调质材料的理想加工刀具，泛用性好；相应一般钨钢，具有2~3倍以上的使用寿命。一般用于良好稳定的工况、良好的零件夹紧及持续中高速轻型的切削加工。TiALN涂层后效果极佳，可加工至HRC60°的各类材料，相应ISO K10～K30/P10～P30。常用于CNC数控设备加工各类高温合金、耐热合金、镍钒钛合金铸铁、不锈钢等难加工材料（含镍、Cr、Mo、硅、钛等）热处理前及调质后的特优秀加工工具。高温加工及综合性能极好，允许切削速度极高（一般线速度为120M以上），进给量要求低些，加工材料的硬度越高，效果越显著。由于韧性差些，不适合于断续切削或在工艺系统刚性不足及有微震动、跳动的条件下使用，否则易打刀或崩刃。
确认被加工材料、硬度HRC、设备刚性（价值）、数量，可依图依样要求研磨成型角度及尺寸公差……只批量现生产，可完全替代国际一流制品，具有极高性价比！
從六轴、七轴联动CNC加工的（A级）高端产品到三轴、四轴生产的（B级）中端制品、不同等級的品質與價位......專業替代一流工业品、特殊、非標、異型、新產品中大批量、超高性價比的研發、生產加工，依圖依樣改進設計，可大大降低綜合成本！
询盘请能提供样品及参考页脚注明每种产品的详细要求、材料种类、尺寸公差、工件成品和半成品图纸、所用的设备、设备价值RMB（以判断其刚性及跳动等）、每月消耗的数量、原用产品类型及其不足之处？被加工材料及其硬度HRC?……
被加工的成品图、注意事项：并能提供使用效果最佳—新的和旧的实样。样品：是易钝化？易崩口？还是……？
拥有先进综合的生产体系，具备各种精密技术生产加工能力，实现高效率、低成本的应用。
Super-hardprocessing of professional, special, non-standard, special shaped and new products with any kind, any shape andtolerance.
※If you have any similar inquiry,please fax us your address or call us to get samples in the photos and relatedcatalogue for your reference (only a small amount is allowed). ※
We keeparound RMB 20～30 Million turnover stock articles suchas raw material ,semi- products,finished products in ordinary year , we are capableto produce according to drawing orsample provided by customer, so as to present you a favorablecost-performance ratio…Welcome to visit our factory。
（Super high wear-resistance/high impact-resistance/high precision）
we can produce super long-wide-thick、high precision、complex profiling productsaccording to requirements of drawings & samples.
VRA201:
Imported ultra micro-grain diamond tungsten steel, with excellentimpact-resistance and general wear-resistance. Generally applied in worse or generalequipment to machine materials of lower hardness （HRC≤25°）, discontinuous cuttingand worse part fixture. Conforming to ISO K25, can replace machining ofmaterials like M42, ASP60, MPM, HSSCo10 etc, and can get 4-6 times lifetime, ithas higher performance/price ration. Comparing with SKH51, it has 15-25 timeslifetime and durability.
MR11: (For high wear-resistant application):
Ultra micro-grain quality carbide has property of excellent wear resistance andideal impact resistance. It is applied in mid, high speed intermediate cuttingmachining of various materials that HRC 28°～48°. It isan ideal machining tooling for finish machining and material tempering, and itis extensively applied. Comparing with general tungsten steel, it has 2~3 timesmore lifetime. Generally it is applied in good and stable work conditions, goodpart fixture and continuous mid, high speed light-duty cutting. After beingTiALN coated, it has better performance, can machine various materials of HRC60° Conforming to ISO K10~K30/P10~P30. It is often applied in CNC equipment tomachine various hard-machining materials (containing Ni, Cr, Mo, Si, Ti etc.)like high temperature alloys, heat-resistant alloys, Ni-V-Ti alloys, cast iron,stainless steel etc., ultra excellent machining tools before heat-treatment andafter tempering. High temperature machining and integrated property is good,allowing highest cutting speed (generally linear speed is above 120M) and with low feed requirement. Thehigher hardness of the machining material, the better performance. Due to itsbad toughness, it is not applicable for discontinuous cutting or for conditionsin which process system's rigidity is not sufficient and there is chattering,jumping, otherwise, the blade will be hit or chipping will happen.
HRF10:
ultra micro-grain quality carbide, has excellent wear resistance, but its impactresistance is not so good. It is applicable for medium and low speed cutting ofhigh hardness materials(HRC45°-65°) requiring thermal refining and quenching orfor various materials having higher wear resistance and non-ferrous metal.Generally it is applied in good working condition\stable cutting\excellent partfixing and continuous light machining. Corresponding to ISO K10.
We adopt various business cooperationmode either royalty or part-time, and media promotion at different time period,as well as technical support and wholesale to middle-scale or large-scaleenterprises or agency, even OEM processing as per customers' requirements. Fromhigh-class products (via 6-axis/ 7-axis Blocking CNC-machine Tool(Class-AAA))to medium-class products (via 3-axis/ 4-axis Blocking CNC-machineTool (Class-D)), different quality and price, our reliable products can replaceto first-class products, and we are professional in wholesale, R&D,producing & processing, as well as design revision according to client'sdesigns and samples of special, non-standard, abnormal shape and new productswith high cost-performance ratio, also our on-demand service will decrease yourcomprehensive cost greatly!
Referencing to the page footer, please provide your sample andspecify the detailed specification, material type, size tolerance, drawing ofsemi-product and finished product, applied equipment, equipment value (RMB, tojudge its market value is rigid orfloating), monthly consumed quantity, type of original product and itsdeficiency, when you make inquiry. What is the processed material and its HRC? Workpiece drawing and notes, and please supply us new and old bestperformedsamples.
Samples: Is it easy to blunt or break or other problems?
LZQ is possessed of cutting-edge &comprehensive production system, as well as rich producing & machiningcapability with different precision technology, so as to realize highefficiency application.
